PI3510U

Specification

Bridge bay size (mm) No bridge box	ChildLock Yes	Energy saving Yes
Heat maintainer Yes	Hob finish No bevelled	Front left heating zone dimension (cm) Nie dotyczy
Front left heating zone power rating (kW) Nie dotyczy	Rear left heating zone dimension (cm) Nie dotyczy	Rear left heating zone power rating (kW) Nie dotyczy
Front middle zone energy consumption F 188.9 Wh/kg	Front middle zone type Induction	Rear middle zone energy consumption R 188.9 Wh/kg
Rear middle zone type Induction	Minute minder Yes	Number of Booster 1
Number of power levels 9	Overflow detection Yes	Overheat detection Yes	Residual heat indicator Yes	Front right heating zone dimension (cm) Nie dotyczy	Rear right heating zone dimension (cm) Nie dotyczy
ø 16 cm 1	ø 20 cm with Power Booster 1	Small object detection Yes	Temperature limiter Yes	Auto switch off Yes	Timer Yes	Hob energy consumption 188.9 Wh/kg	Control type Touch control

Power indicator lamp Yes

Frequency 50	Can be built flush with the top Yes	Connection cable colour White
Connection type 1N~230 V	Cut out size - depth 49 cm	Cut out size - width 28.5 cm
Display color Red	Edge finish C-cut	Gross volume 0.0313 m³
Total power of hob 3.7 kW	In-furniture depth 6.8 cm	Rear middle zone size (cm) 20
Net depth 52.2 cm	Net height 7.2 cm	Net weight 5.6 kg
Net width 30 cm	Number of heating elements 2	Type of plug or cable Euro 3x0.75mm2
Position Of Connection Cable Right - rear	Connection cable Power cord with plug	Power cabel length 130 cm
Power Supply Voltage 230V	Power Supply Voltage 230V	Hob type Induction
